Wieland Industrial Connector Housing - 10 Pole M20, Aluminum
Wieland Industrial Connector Housing - 10 Pole M20, Aluminum
SKU:IND-121b99
Wieland 10-Pole Industrial Connector Housing with Aluminum Construction, IP54 Rated, Single Locking Lever
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing - 10 Pole M20, Aluminum
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing - 10 Pole M20, Aluminum
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GT 10 M20 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is designed for industrial applications, featuring a durable aluminum construction with a powder coating for longevity. It includes a single locking lever and a sideways cable entry with a gland nut for secure connections. With a protective cover rated IP54, this low-profile housing offers resistance to UV exposure and a wide operating temperature range from -40°C to 120°C, ensuring reliability in various environments. Compliant with RoHS standards and suitable for heavy-duty use, this connector housing guarantees high performance and safety.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GT 10 M20 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
10
Model Emc Version
No
Model Height
55 mm
Model Hinged Lid
Yes
Model Length
94 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Surface Mounting (Base)
Model Type Of Cable
Gland nut
Model Width
52 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a); III-6(c)
Specifications Number Of Poles
10
Specifications Profile
Low
