Wieland Industrial Connector Housing - 10-Pole M25 A0, Aluminum, IP54
Wieland Industrial Connector Housing - 10-Pole M25 A0, Aluminum, IP54
SKU:IND-49c3af
Durable Wieland 10-Pole Connector Housing with IP54, Aluminum Construction, Double Locking Lever, M25 Cable Gland
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing - 10-Pole M25 A0, Aluminum, IP54
$69.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing - 10-Pole M25 A0, Aluminum, IP54
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GF 10 M25 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a premium solution for industrial multipole connectivity. Constructed from durable aluminum with a gray powder-coated surface, this housing features a double locking lever and a cable gland M25 on top for IP54 protection. With a low profile design and 10 poles, it ensures reliable connections in harsh environments. UV-resistant and operable within a wide temperature range from -40°C to 120°C, this connector housing offers robust performance and longevity for industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GF 10 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
56 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
10
Specifications Profile
Low
