Wieland Industrial Connector Housing - 10 Pole Male, M25 Thread, Aluminum Construction
Wieland Industrial Connector Housing - 10 Pole Male, M25 Thread, Aluminum Construction
SKU:IND-efd03a
Secure and durable Wieland Industrial Connector Housing for 10 poles, M25 thread, with IP54 protection and RoHS compliance.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing - 10 Pole Male, M25 Thread, Aluminum Construction
$59.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing - 10 Pole Male, M25 Thread, Aluminum Construction
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GI 10 M25 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is designed for industrial applications requiring secure connections. Crafted from robust aluminum with a powder-coated gray finish, this housing offers reliable IP54 protection with UV resistance. It features a single locking lever, M25 threaded hole, and accommodates 10 poles. With a temperature range of -40°C to 120°C, it ensures dependable performance under varying conditions. Compliant with RoHS standards and featuring lead-free components, this housing prioritizes safety and sustainability.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GI 10 M25 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
89 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a); III-6(c)
Specifications Number Of Poles
10
Specifications Profile
Low
