Wieland Industrial Connector Housing 15-Pole Heavy Duty Aluminum
Wieland Industrial Connector Housing 15-Pole Heavy Duty Aluminum
SKU:IND-5b37b0
Durable Wieland 15-Pole Industrial Connector Housing with double locking lever, UV resistant, and IP54 protection.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing 15-Pole Heavy Duty Aluminum
$59.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing 15-Pole Heavy Duty Aluminum
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM HD GUT GK 15 50 A Multi-Pole Heavy-Duty Industrial Connector Housing is a reliable solution for industrial connectivity. Constructed with durable aluminum and featuring a double locking lever, this housing ensures secure connections. With a low-profile design and IP54 protection, it offers resistance to UV exposure and a wide temperature range from -40°C to 120°C. Compliant with REACH-SVHC regulations, this 15-pole housing meets industry standards for safety and performance.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM HD GUT GK 15 50 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
10/15
Model Emc Version
81 mm
Model Hinged Lid
No
Model Length
30.4 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size Pg
No
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
25.7 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
15
Specifications Profile
Low
