Wieland Industrial Connector Housing - 24-Pole Heavy-Duty Aluminum Hood with M25 Cable Gland
Wieland Industrial Connector Housing - 24-Pole Heavy-Duty Aluminum Hood with M25 Cable Gland
SKU:IND-ba1f72
Wieland 24-Pole Heavy-Duty Aluminum Connector Housing with M25 Cable Gland. IP54 Rated, UV Resistant, RoHS Compliant.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing - 24-Pole Heavy-Duty Aluminum Hood with M25 Cable Gland
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing - 24-Pole Heavy-Duty Aluminum Hood with M25 Cable Gland
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GC 24 M25 A0 Multi-Pole Connector Housing is a heavy-duty aluminum hood designed for industrial applications. Featuring a low-profile design with a powder-coated gray surface, this housing ensures durability and protection with an IP54 rating. Equipped with double locking levers or screw cap options and a cable gland M25 on top, it offers secure cable connections. With a temperature range of -40°C to 120°C, UV resistance, and compliance with RoHS standards, this housing meets stringent industrial requirements for reliability and safety.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GC 24 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
24
Model Emc Version
No
Model Height
70 mm
Model Hinged Lid
No
Model Length
120 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
57 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
24
Specifications Profile
Low
