Wieland Industrial Connector Housing 6-Pole Aluminum M25 Threaded High Version
Wieland Industrial Connector Housing 6-Pole Aluminum M25 Threaded High Version
SKU:IND-b13caa
Durable Wieland 6-Pole Aluminum Industrial Connector Housing with M25 Threaded Hole & High UV Resistance
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing 6-Pole Aluminum M25 Threaded High Version
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing 6-Pole Aluminum M25 Threaded High Version
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GG 6HM25 69 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is designed for industrial applications requiring a robust connector solution. Constructed from aluminum with a gray powder coating, this housing ensures durability and protection. Featuring a single locking lever with a threaded hole M25 on the right side, this high profile connector accommodates 6 poles. With a temperature range from -40°C to 120°C and UV resistance, it guarantees reliable performance in various environments. Compliant with REACH-SVHC standards, this connector housing meets quality and regulatory requirements.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 6HM25 69 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
6
Model Emc Version
No
Model Height
70 mm
Model Hinged Lid
No
Model Length
74 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
6
Specifications Profile
High
