Wieland Industrial Connector Housing - 6-Pole Multipole Aluminum Hood with Single Locking Lever
Wieland Industrial Connector Housing - 6-Pole Multipole Aluminum Hood with Single Locking Lever
SKU:IND-27321b
Enhance your industrial connections with the Wieland aluminum multipole connector housing, featuring single locking lever and 6 poles.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing - 6-Pole Multipole Aluminum Hood with Single Locking Lever
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing - 6-Pole Multipole Aluminum Hood with Single Locking Lever
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial connections with the Wieland HOOD BAS GOT GL 6 M20 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing. This robust aluminum housing features a single locking lever, M20 threaded hole for secure cable connections, and a low-profile design for space efficiency. With IP54 protection, UV resistance, and a wide temperature range from -40°C to 120°C, this housing ensures reliable performance in various environments. Compliant with REACH-SVHC standards and boasting 6 poles, this housing is a trusted choice for demanding industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GL 6 M20 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
6
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
74 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Cable Coupler
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
6
Specifications Profile
Low
