Wieland Industrial Connector Housing M25 16-Pole
Wieland Industrial Connector Housing M25 16-Pole
SKU:IND-6115eb
Durable Wieland Industrial Connector Housing for 16 poles with aluminum construction, double locking lever, and IP54 protection. UV resistant and RoHS compliant.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Industrial Connector Housing M25 16-Pole
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Connector Housing M25 16-Pole
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Industrial Connector Housing M25 16-Pole is a heavy-duty solution for industrial applications. Constructed with durable aluminum and featuring a double locking lever and trumpet gland M25 for IP54 protection. This low-profile housing is UV resistant, with a wide operating temperature range of -40°C to 120°C. With 16 poles and compliant with RoHS standards, it ensures reliable connectivity in demanding environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GD 16 M25 A3
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16
Model Emc Version
No
Model Height
60 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
56 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
16
Specifications Profile
Low
