Wieland Industrial Male Connector Insert EX STS 24 2.5 09IA
Wieland Industrial Male Connector Insert EX STS 24 2.5 09IA
SKU:IND-1d0cb2
Reliable Wieland Industrial Male Connector Insert for secure and durable connections in industrial environments.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland Industrial Male Connector Insert EX STS 24 2.5 09IA
$34.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Male Connector Insert EX STS 24 2.5 09IA
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Industrial Male Connector Insert EX STS 24 2.5 09IA is a reliable solution for industrial multipole connectors. With a durable construction and screw connection type, this male insert features 24 poles suitable for various applications. The copper alloy contacts with tin-plated surface ensure secure connections with low contact resistance. Compliant with RoHS and REACH regulations, this connector insert meets the highest standards for safety and environmental protection. Rated for a nominal voltage of 90 V, it operates at a maximum temperature of 60°C, making it ideal for industrial environments.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Number Of Poles
24
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠1.5 mΩ
Contacts Surface
Tin-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Blue
General Explosion Tested Version
Yes
General Mating Cycles
200
General Maximum Operating Temperature
60 ºC
General Model
MALE INSERT EX STS 24 2,5 09IA
General Pollution Degree
3
General Type
Male Insert
Note Note
Max. Input current 16A by permitted wire cross section 1.5 till 2.5mm²; Max. Input current 10A by permitted wire cross section 1.0 mm²; Max. Input current 6 A by permitted wire cross section 0.75 mm²; Max. Input current 3 A by permitted wire cross section
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Din En 61984 Nominal Voltage
90 V
Technical Data Ulcsa Maximum Flexible Wire Conductor Cross Secti
2.5 mm²
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
0.5 mm²
