Wieland Industrial Multi-Pole Connector - 6 Pole Aluminum Hood with M20 Cable Gland
Wieland Industrial Multi-Pole Connector - 6 Pole Aluminum Hood with M20 Cable Gland
SKU:IND-3ef4de
Rugged 6-pole aluminum industrial connector housing with M20 cable gland, IP54 rated, UV-resistant, RoHS-compliant.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland Industrial Multi-Pole Connector - 6 Pole Aluminum Hood with M20 Cable Gland
$59.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Multi-Pole Connector - 6 Pole Aluminum Hood with M20 Cable Gland
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GI 6 M20 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a premium solution for industrial connectivity. Constructed from durable aluminum with a gray powder coating, this housing features a single locking lever for secure connections. With a degree of protection (IP) rating of IP54, it ensures reliable performance in challenging environments. This low-profile housing is UV-resistant, flame-retardant, and operates within a temperature range of -40°C to 120°C. Ideal for 6-pole configurations, it comes with a cable gland M20 on the top for easy cable entry. Compliant with RoHS standards, this connector housing meets the highest quality and safety requirements.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GI 6 M20 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
6
Model Emc Version
No
Model Height
51 mm
Model Hinged Lid
No
Model Length
73.6 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
6
Specifications Profile
Low
