Wieland Industrial Multi-Pole Connector Housing - 10P Aluminum Hood with M32 Threaded Hole
Wieland Industrial Multi-Pole Connector Housing - 10P Aluminum Hood with M32 Threaded Hole
SKU:IND-548a06
Enhance your industrial connections with the Wieland 10P Aluminum Connector Housing
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Industrial Multi-Pole Connector Housing - 10P Aluminum Hood with M32 Threaded Hole
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Multi-Pole Connector Housing - 10P Aluminum Hood with M32 Threaded Hole
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial connections with the Wieland HOOD BAS GOT GC 10HM32 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing. This aluminum housing features a low-profile design with a double locking lever or screw cap for secure fastening. With a 10-pole construction and UV resistance, it ensures durability in challenging environments. Suitable for temperatures ranging from -40°C to 120°C, this housing maintains reliable performance. Compliant with REACH-SVHC standards, it meets quality and environmental regulations, making it a reliable choice for industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GC 10HM32 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
10H
Model Emc Version
No
Model Height
70 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
32
Model Type
Male
Model Type Of Cable
Thread
Model Width
56 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
10
Specifications Profile
Low
