Wieland Industrial Multipole Connector Housing - 10-Pole M20 A1
Wieland Industrial Multipole Connector Housing - 10-Pole M20 A1
SKU:IND-4e0c84
Durable Wieland 10-Pole Industrial Connector Housing for secure cable connections. Aluminum construction, UV-resistant, and compliant with REACH-SVHC standards.
Regular price
$74.99
Regular price
Sale price
$74.99
Unit price
per
Initiate Order
Wieland Industrial Multipole Connector Housing - 10-Pole M20 A1
$74.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial Multipole Connector Housing - 10-Pole M20 A1
$74.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GA 10 M20 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is designed for industrial applications, featuring a durable aluminum construction with UV resistance. With a low-profile design and 10 poles, this housing ensures secure cable connections with double locking levers for added safety. It meets compliance with REACH-SVHC standards and operates within a wide temperature range from -40°C to 120°C, making it ideal for demanding environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GA 10 M20 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
10
Specifications Profile
Low
