Wieland IP54 Aluminum Industrial Connector Housing 6-Pole M25
Wieland IP54 Aluminum Industrial Connector Housing 6-Pole M25
SKU:IND-b00af9
Wieland Aluminum Industrial Connector Housing with Single Locking Lever & 6 Poles
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland IP54 Aluminum Industrial Connector Housing 6-Pole M25
$59.99
Quantity: 1
Claim Your Seller Account
Wieland IP54 Aluminum Industrial Connector Housing 6-Pole M25
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GG 6 M25 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a high-quality, aluminum construction connector hood designed for industrial applications. Featuring a single locking lever and a cable gland M25 on the right side, this IP54-rated housing ensures protection against dust and water ingress. With a low profile design, this housing accommodates 6 poles and is UV resistant, making it suitable for a wide range of environmental conditions. It meets RoHS compliance standards and is designed for reliable performance in temperature ranges from -40°C to 120°C.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 6 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
6
Model Emc Version
No
Model Height
51 mm
Model Hinged Lid
No
Model Length
73.6 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
6
Specifications Profile
Low
