Wieland Light Blue Distributor Block - 2/3 Poles
Wieland Light Blue Distributor Block - 2/3 Poles
SKU:CIR-6fed5e
High-quality Wieland Distributor Block - 2/3 Poles, ideal for outdoor use. Meets IEC and cULus standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland Light Blue Distributor Block - 2/3 Poles
$29.99
Quantity: 1
Claim Your Seller Account
Wieland Light Blue Distributor Block - 2/3 Poles
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Light Blue Distributor Block is a versatile solution for distributing power efficiently. This block supports 2 or 3 poles, accommodating cables with diameters ranging from 5.0 to 9.5 mm. With a minimum rated voltage of 250 V, maximum rated voltage of 600 V, and a rated current of 16 A, it meets rigorous IEC and cULus standards. Its IP69 and Type 4X protection levels ensure durability in harsh environments. The fastening option to the mounting plate simplifies installation, making it ideal for outdoor applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Blue
Model Number Of Inputs
1
Model Number Of Outputs
2
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
300 V
Technical Data Cable Diameter
5.0 to 9.5 mm
Technical Data Current Disconnect Under Load
16 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Number Of Poles
2 | 3
Technical Data Rated Current
16 A
Technical Data Wire Size According To Canadian Ul Listed United
24 to 16 AWG
Technical Data Wire Size According To International Electrotechn
0.25 to 1.5 mm²
