Wieland Light Blue Female Splitter Connector 6mm Cable Diameter
Wieland Light Blue Female Splitter Connector 6mm Cable Diameter
SKU:CIR-fc551c
Reliable Wieland Female Splitter Connector in Light Blue for outdoor electrical connections with a 6mm cable diameter and 7 poles. cULus-Listed & IEC compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland Light Blue Female Splitter Connector 6mm Cable Diameter
$24.99
Quantity: 1
Claim Your Seller Account
Wieland Light Blue Female Splitter Connector 6mm Cable Diameter
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Female Splitter Connector in Light Blue is a reliable solution for outdoor electrical connections. Featuring a 6mm minimum cable diameter and 7 poles, this connector is cULus-Listed and IEC compliant. With a screw connection type, it supports voltages up to 600V and offers a high degree of protection with an IP69 rating. Meeting international standards, this connector ensures secure and efficient power transmission in demanding environments.
Product Specifications
Note Note
Technical details are subject to change
Specifications Color Of Codingcontact Carrier
Light Blue
Specifications Connection Type
Screw Connection
Specifications Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) | 3 x 20 A + 4 x 5 A (USA)
Specifications Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Specifications Degree Of Protection According To Canadian Ul Rec
Type 4X/6P
Specifications Degree Of Protection According To International E
IP69
Specifications Maximum Cable Diameter
10 mm
Specifications Minimum Cable Diameter
6 mm
Specifications Model
Female
Specifications Number Of Poles
7
Specifications Standards
cULus-Listed | IEC
Specifications Voltage
250 V | 400 V | 600 V
Specifications Wire Size According To Canadian Ul Recognized Uni
20 to 14 AWG
Specifications Wire Size According To International Electrotechn
0.2 to 1.5 mm²
