Wieland Light Gray 2-Pole Female Connector - 20A
Wieland Light Gray 2-Pole Female Connector - 20A
SKU:CIR-372215
Durable Wieland Light Gray 2-Pole Female Connector for outdoor use with screw connection. Rated 250-600V, 20A. Straight angle plug.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland Light Gray 2-Pole Female Connector - 20A
$29.99
Quantity: 1
Claim Your Seller Account
Wieland Light Gray 2-Pole Female Connector - 20A
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Light Gray 2-Pole Female Connector is a durable and reliable pluggable electrical connector designed for outdoor use. With a straight angle plug and screw connection, this connector is rated for 250V to 600V and 20A current, meeting international standards for cable diameters, wire sizes, and IP69 protection. Ideal for applications requiring a secure and weather-resistant electrical connection.
Product Specifications
Note Note
Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
2
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Rated Current Canada
15 A
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
