Wieland Light Gray 6mm Female Splitter Connector

Name: Wieland Light Gray 6mm Female Splitter Connector
Brand: Wieland Electric Inc.
SKU: CIR-039441
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-039441

Enhance connections with Wieland's Female Splitter Connector. Outdoor-rated, light gray with 6mm cable diameter, and cULus-Listed/IEC compliant.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your electrical connections with the Wieland Female Splitter Connector. This outdoor-rated circular electrical connector features a light gray color for easy coding, screw connection type, and meets cULus-Listed and IEC standards. With a 6mm minimum cable diameter and IP69 protection, this connector ensures reliable performance in demanding environments.

Product Specifications

Note Note

Technical details are subject to change

Specifications Color Of Codingcontact Carrier

Light Gray

Specifications Connection Type

Screw Connection

Specifications Current According To Canadian Ul Recognized Unite

3 x 16 A + 4 x 2 A (Canada) | 3 x 20 A + 4 x 5 A (USA)

Specifications Current According To International Electrotechnic

3 x 20 A + 4 x 5 A

Specifications Degree Of Protection According To Canadian Ul Rec

Type 4X/6P

Specifications Degree Of Protection According To International E

IP69

Specifications Maximum Cable Diameter

10 mm

Specifications Minimum Cable Diameter

6 mm

Specifications Model

Female

Specifications Number Of Poles

Specifications Standards

cULus-Listed | IEC

Specifications Voltage

250 V | 400 V | 600 V

Specifications Wire Size According To Canadian Ul Recognized Uni

20 to 14 AWG

Specifications Wire Size According To International Electrotechn

0.2 to 1.5 mmÂ²
