Wieland LPST 1/5 PCB Edge Connector with Screw Connection
Wieland LPST 1/5 PCB Edge Connector with Screw Connection
SKU:PRI-7413ac
Wieland LPST 1/5 PCB Edge Connector: 5-pole screw connection, no soldering, 2.5mm² cross-section, 5A rated current.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland LPST 1/5 PCB Edge Connector with Screw Connection
$24.99
Quantity: 1
Claim Your Seller Account
Wieland LPST 1/5 PCB Edge Connector with Screw Connection
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland LPST 1/5 PCB Edge Connector features a 5-pole design with screw connection, perfect for PCBs with marking. With a modular spacing of 5mm, this connector offers easy installation without the need for soldering. It boasts a nominal cross-section of 2.5mm², a rated current of 5A, and impressive overvoltage protection up to 4kV. The connector's thermoplastic insulation, silver contact surface, and copper silicone base material ensure durability and reliable performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
4 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
General Brands
Wieland
General Connection Type
Screw Connection
General Marking
Yes
General Mating Direction Towards Connector
90 º
General Maximum Printed Circuit Board Pcb Thickness
1.4 mm
General Minimum Printed Circuit Board Pcb Thickness
1.8 mm
General Model
LPST 1 / 5
General Modular Spacing
5 mm
General Number Of Poles
5
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicone (CuSn)
Other Contact Surface Material
Silver (Ag)
Other Depth
16 mm
Other Height
13 mm
Other Length
29 mm
Other Material Attachment Screw
Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
320 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
5 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
