Wieland Multi-Pole Aluminum Connector Housing M20 with IP54 Protection
Wieland Multi-Pole Aluminum Connector Housing M20 with IP54 Protection
SKU:IND-df6f06
Durable Wieland Multi-Pole Aluminum Connector Housing with M20 Cable Gland and IP54 Protection. Ideal for industrial use.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland Multi-Pole Aluminum Connector Housing M20 with IP54 Protection
$59.99
Quantity: 1
Claim Your Seller Account
Wieland Multi-Pole Aluminum Connector Housing M20 with IP54 Protection
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GC 10 M20 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a durable solution designed for industrial applications. Constructed from aluminum with a gray powder coating, this 10-pole connector housing features a double-locking lever mechanism and a cable gland M20 for secure connections. With a temperature range from -40°C to 120°C, UV resistance, and IP54 protection, it ensures reliable performance in various environments. Compliant with RoHS standards, this product meets stringent quality and safety requirements, making it an ideal choice for industrial and institutional settings.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GC 10 M20 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
10
Specifications Profile
Low
