Wieland Multi-Pole Heavy-Duty Industrial Connector Housing
Wieland Multi-Pole Heavy-Duty Industrial Connector Housing
SKU:IND-2c24cb
Durable Wieland Industrial Connector Housing with 10-pole configuration, secure double locking levers, and UV resistance for reliable performance.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Multi-Pole Heavy-Duty Industrial Connector Housing
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Multi-Pole Heavy-Duty Industrial Connector Housing
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Multi-Pole Heavy-Duty Industrial Connector Housing is a top-of-the-line solution for industrial applications. Constructed from durable aluminum with a powder coating, this housing features a low profile design, double locking levers for secure connections, and a threaded hole size M25 for easy cable entry. With a 10-pole configuration and UV resistance, it ensures reliable performance in a wide temperature range from -40 ºC to 120 ºC. Compliant with REACH-SVHC standards, this housing is a trusted choice for demanding industrial environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GA 10 M25 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
10
Specifications Profile
Low
