Wieland Multi-Pole Industrial Connector Housing - 10 Pole M20 A1
Wieland Multi-Pole Industrial Connector Housing - 10 Pole M20 A1
SKU:IND-d5994b
Durable aluminum industrial connector housing with 10 poles, M20 threaded holes, single locking lever, and protective cover. UV resistant, RoHS compliant.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Multi-Pole Industrial Connector Housing - 10 Pole M20 A1
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Multi-Pole Industrial Connector Housing - 10 Pole M20 A1
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial connectivity with the Wieland BOTTOM BAS GUT GR 10 M20 A1 Multi-Pole Heavy-Duty Industrial Connector Housing. Constructed with durable aluminum in a low-profile design, this housing features a single locking lever, threaded M20 holes on both sides, and a protective cover for enhanced safety. With UV resistance and a wide temperature range (-40°C to 120°C), this surface-mounting base meets RoHS standards and offers 10 poles for efficient cable management.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GR 10 M20 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Two-sided
Model Construction
10
Model Emc Version
No
Model Height
55 mm
Model Hinged Lid
Yes
Model Length
94 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Surface Mounting (Base)
Model Type Of Cable
Thread
Model Width
52 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
10
Specifications Profile
Low
