Wieland PCB Terminal Block 8142 Z/ 2 RF OB SW
Wieland PCB Terminal Block 8142 Z/ 2 RF OB SW
SKU:PRI-bbe059
High-quality pluggable terminal block with screw connection, 2-pole snap-in design, 5mm pitch, and RoHS compliant
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Wieland PCB Terminal Block 8142 Z/ 2 RF OB SW
$12.99
Quantity: 1
Claim Your Seller Account
Wieland PCB Terminal Block 8142 Z/ 2 RF OB SW
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland PCB Terminal Block 8142 Z/ 2 RF OB SW is a high-quality pluggable terminal block featuring screw connection in rising cage technology. Designed for PCB with stripped headers, this 2-pole snap-in terminal block offers a pitch of 5mm. With a modular spacing of 5 mm, this terminal block is ideal for applications requiring reliable connections without the need for soldering. It has a nominal cross-section of 2.5 mm² and a rated current of 3 A, ensuring dependable performance. In addition, this terminal block complies with RoHS and REACH-SVHC standards, making it environmentally friendly and safe for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.5 mm²
Connection Data Minimum Solid Cross Section
0.5 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Marking
No
General Mating Direction Towards Connector
90 º
General Model
PCB TERMINAL 8142 Z/ 2 RF OB SW
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
2
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
12.6 mm
Other Height
10.7 mm
Other Length
10 mm
Other Material Attachment Screw
Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
320 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
3 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Cross Section Canadian Standards Associatio
20-14 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
20-14 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
