Wieland Podis LED Lamp - Industrial Grade Green Light
Wieland Podis LED Lamp - Industrial Grade Green Light
SKU:POD-d61e16
Energy-saving industrial LED lamp for harsh environments, providing 290 lm of green light at 24 VDC. IP68/IP69K housing with reverse polarity, overload, and short circuit protection. Compliant with EN 60598-2-22 and EN 60598-1.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland Podis LED Lamp - Industrial Grade Green Light
$69.99
Quantity: 1
Claim Your Seller Account
Wieland Podis LED Lamp - Industrial Grade Green Light
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Meet your industrial lighting needs with the Wieland Podis LED Lamp. Designed for harsh environments like wind turbines, this energy-saving LED luminaire provides 290 lm of green light at 24 VDC. With reverse polarity, overload, and short circuit protection, it ensures safety and reliability. Encapsulated in IP68/IP69K housing, operating from -40 to +70°C, it complies with EN 60598-2-22 and EN 60598-1 standards, delivering exceptional performance and durability.
Product Specifications
Classification Eclass 81 Classification
27110640
Classification Etim 40 Classification
EC001959
Classification Etim 50 Classification
EC001959
Classification Etim 60 Classification
EC001959
Classification Etim 70 Classification
EC001959
Classification Etim 80 Classification
EC001959
Classification Etim 90 Classification
EC001959
Dimensions Height
76 mm
Dimensions Length
160 mm
Dimensions Width
104 mm
General Brands
Wieland
General Circuit
Other
General Color Housing
Light Gray
General Degree Of Protection Ip
IP65 | IP67 | IP69
General Housing Material
Plastic
General Lamp
Light Emitting Diode (LED)
General Lamp Holder
Other
General Mounting Method
Wall
General Power Supply Connection
Plug Connection Reference, Secondary, and Tertiary (RST)
General Wiring System
Continuous Circuit | Standby Circuit
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Direct Current Dc Voltage
24 V
Technical Data Emergency Lighting Characterization
Z 1 ***D
Technical Data Fuse Current
0.5 A
Technical Data Fuse Voltage
60 V (Resetting)
Technical Data Maximum Ambient Operating Temperature
70 ºC
Technical Data Maximum Nominal Voltage
32 V
Technical Data Maximum Storagetransport Temperature
70 ºC
Technical Data Minimum Ambient Operating Temperature
-40 ºC
Technical Data Minimum Nominal Voltage
15 V
Technical Data Minimum Storagetransport Temperature
-40 ºC
Technical Data Mode
Constant Current
Technical Data Reverse Polarity Protection
Yes
Technical Data Standards
DIN EN60598-1 | DIN EN60598-22
