The Wieland Podis LED Lamp offers superior illumination with a power-efficient design. Featuring a Polyamide housing, this lamp is suitable for ceiling or wall mounting. With a nominal voltage range of 200-250V, constant current mode, and IP65 protection rating, this lamp ensures reliable performance in various environments. Compliant with DIN EN60598-1 and DIN EN60598-22 standards, it guarantees safety and quality for your lighting needs.
Product Specifications
Classification Eclass 81 Classification
27110640
Classification Etim 40 Classification
EC001959
Classification Etim 50 Classification
EC001959
Classification Etim 60 Classification
EC001959
Classification Etim 70 Classification
EC001959
Classification Etim 80 Classification
EC001959
Classification Etim 90 Classification
EC001959
Dimensions Height
82 mm
Dimensions Length
180 mm
Dimensions Width
130 mm
General Brands
Wieland
General Circuit
Other
General Color Housing
Black
General Degree Of Protection Ip
IP65
General Housing Material
Polyamide
General Lamp
Light Emitting Diode (LED)
General Lamp Holder
Other
General Mounting Method
Ceiling | Wall
General Power Supply Connection
Plug Connection Reference, Secondary, and Tertiary (RST)
General Wiring System
Continuous Circuit | Standby Circuit
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Emergency Lighting Characterization
Z 1 ***DE
Technical Data Fuse Current
T2
Technical Data Fuse Direct Current Dc Voltage
250 V (Internal)
Technical Data Lamp Power
6 W | 300 lm
Technical Data Light Color
5000 K
Technical Data Maximum Ambient Operating Temperature
50 ºC
Technical Data Maximum Nominal Voltage
250 V
Technical Data Maximum Storagetransport Temperature
70 ºC
Technical Data Minimum Ambient Operating Temperature
-40 ºC
Technical Data Minimum Nominal Voltage
200 V
Technical Data Minimum Storagetransport Temperature
-40 ºC
Technical Data Mode
Constant Current
Technical Data Reverse Polarity Protection
No
Technical Data Standards
DIN EN60598-1 | DIN EN60598-22
