Wieland RST20I2 Female Device Connector - M20 Thread, Light Gray, 2 Poles, 20A
Wieland RST20I2 Female Device Connector - M20 Thread, Light Gray, 2 Poles, 20A
SKU:CIR-2b3910
Wieland RST20I2 Female Device Connector - Outdoor Circular Electrical Connector, M20 Thread, 2 Poles, 20A
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I2 Female Device Connector - M20 Thread, Light Gray, 2 Poles, 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I2 Female Device Connector - M20 Thread, Light Gray, 2 Poles, 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I2 Female Device Connector in light gray color features a screw connection and is designed for outdoor use. With a thread size of M20 and a straight plug angle, this connector is rated for 20A current with voltage ratings up to 600V. It meets IP69 and Type 4X/6P protection standards, ensuring durability in harsh environments. This connector accommodates wires ranging from 0.75 to 6 mm² per IEC standards, making it ideal for a wide range of applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Connector Type
Female
General Maximum Rated Voltage
600 V
General Minimum Rated Voltage
250 V | 400 V
General Model
RST20I2 Female
General Number Of Poles
2
General Rated Current
20 A
General Rated Current Canada
15 A
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
