Wieland RST20I2 Male Connector, M25 Thread, Light Gray
Wieland RST20I2 Male Connector, M25 Thread, Light Gray
SKU:CIR-244532
High-quality Wieland RST20I2 Male Device Connector with IP69 rating, ideal for outdoor use. Thread size M25, light gray color.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland RST20I2 Male Connector, M25 Thread, Light Gray
$29.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I2 Male Connector, M25 Thread, Light Gray
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I2 Male Device Connector in Light Gray is a high-quality circular electrical connector designed for outdoor use. With an IP69 rating and a durable spring clamp connection, this connector ensures a secure and reliable electrical connection. It features 2 poles, rated current up to 20A, and a thread size of M25, suitable for cable diameters ranging from 6 to 18 mm. Meeting international standards like IEC and CSA, this connector guarantees performance and safety in demanding environments.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Spring Clamp Connection
General Connector Type
Male
General Maximum Rated Voltage
600 V
General Minimum Rated Voltage
250 V | 400 V
General Model
RST20I2 Male
General Number Of Poles
2
General Rated Current
20 A
General Rated Current Canada
15 A
Note Note
Technical details are subject to change
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Cable Diameter
10 to 14 mm | 13 to 18 mm | 6 to 10 mm
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Thread Size
M25
Technical Data Wire Size According To Canadian Standards Associa
16 to 12 AWG
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.50 to 2.5 mm²
