Wieland RST20I5 5-Pole Female Device Connector, Turquoise Blue
Wieland RST20I5 5-Pole Female Device Connector, Turquoise Blue
SKU:CIR-06d652
Get secure connections with Wieland RST20I5 Female Device Connector in Turquoise Blue. Outdoor-rated, 20A rated current, IP69 protection.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I5 5-Pole Female Device Connector, Turquoise Blue
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 5-Pole Female Device Connector, Turquoise Blue
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Female Device Connector in Turquoise Blue offers a reliable screw connection with a straight angle plug. This outdoor-rated circular electrical connector is designed for durability and performance. With a rated current of 20A and IP69 degree of protection, it ensures safe and secure connections in various settings. Compliant with international standards, including IEC and cULus, this connector accommodates wire sizes ranging from 0.75 to 4 mm² and 18 to 14 AWG.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Turquoise Blue
General Connection Type
Screw Connection
General Model
RST20I5 Female
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
