Wieland RST20I5 Female Device Connector, 90 Degree Angle, Light Gray

Name: Wieland RST20I5 Female Device Connector, 90 Degree Angle, Light Gray
Brand: Wieland Electric Inc.
SKU: CIR-88dbb6
Price: 24.99 USD
Availability: OutOfStock

SKU:CIR-88dbb6

Reliable Wieland RST20I5 Female Device Connector for outdoor use, screw connection, 90-degree angle, 5 poles.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland RST20I5 Female Device Connector is a high-quality circular electrical connector suitable for outdoor use. Featuring a screw connection and an angled 90-degree plug, this connector is designed for reliability and ease of installation. With a light gray color and 5 poles, it meets international standards for voltage, current, and protection ratings, making it ideal for commercial and industrial applications.

Product Specifications

General Angle Of Plug

Angled 90Âº

General Brands

Wieland

General Color Of Codingcontact Carrier

Light Gray

General Connection Type

Screw Connection

General Model

RST20I5 Female

General Number Of Poles

Note Note

Technical details are subject to change

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Thread Size

M25

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²

Wieland RST20I5 Female Device Connector, 90 Degree Angle, Light Gray
