Wieland RST20I5 Female Device Connector, Light Gray 90° Angle Plug, Outdoor Rated

Name: Wieland RST20I5 Female Device Connector, Light Gray 90° Angle Plug, Outdoor Rated
Brand: Wieland Electric Inc.
SKU: CIR-44c237
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-44c237

Wieland RST20I5 Female Device Connector with 90° Angle Plug, Outdoor Rated, 5 Poles, IP69 Protection

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland RST20I5 Female Device Connector in light gray features a 90-degree angled plug for convenient installation. With 5 poles and a screw connection, this connector is designed for outdoor applications. It meets stringent specifications with a rated current of 20 A, IP69 protection level, and compatibility with wire sizes ranging from 0.75 to 4 mm² (IEC) or 18 to 14 AWG (cULus). This device connector ensures reliable performance in various environments.

Product Specifications

General Angle Of Plug

Angled 90Âº

General Brands

Wieland

General Color Of Codingcontact Carrier

Light Gray

General Connection Type

Screw Connection

General Model

RST20I5 Female

General Number Of Poles

Note Note

Technical details are subject to change

Specifications Type

Female

Technical Data Alternating Current Ac Voltage Disconnect Under L

350 V

Technical Data Current Disconnect Under Load Usa And Canada

20 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X / 6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Rated Current

20 A

Technical Data Thread Size

M20

Technical Data Wire Size According To Canadian Ul Listed United

18 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.75 to 4 mmÂ²
