Wieland RST20I5 Female Device Connector - Light Gray Color, Straight Angle Plug
Wieland RST20I5 Female Device Connector - Light Gray Color, Straight Angle Plug
SKU:CIR-6a6390
High-performance Wieland RST20I5 Female Device Connector in Light Gray for outdoor electrical applications. IP69 & Type 4X/6P rated, 600V/20A. Durable screw connection.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I5 Female Device Connector - Light Gray Color, Straight Angle Plug
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 Female Device Connector - Light Gray Color, Straight Angle Plug
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Female Device Connector in Light Gray features a durable screw connection with a straight angle plug design. With 5 poles, this connector is rated for voltages up to 600V and currents of 20A, suitable for various electrical applications. Compliant with IP69 and Type 4X/6P protection standards, it ensures reliable performance in outdoor settings while accommodating wire sizes from 0.75 to 4 mm² (IEC) and 18 to 14 AWG (cULus). Stay connected securely with this premium connector designed for resilience and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Model
RST20I5 Female
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Female
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
