Wieland RST20I5 Male 90-Degree Angle Plug Device Connector, Light Blue
Wieland RST20I5 Male 90-Degree Angle Plug Device Connector, Light Blue
SKU:CIR-3ac724
Secure your outdoor connections with the Wieland RST20I5 Male 90-Degree Angle Plug Device Connector in light blue.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland RST20I5 Male 90-Degree Angle Plug Device Connector, Light Blue
$29.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 Male 90-Degree Angle Plug Device Connector, Light Blue
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Male Device Connector features a 90-degree angled plug in a distinctive light blue color. With 5 poles and a screw connection type, this connector is ideal for outdoor applications, offering a secure and reliable connection. It meets international standards with a minimum rated voltage of 250V, maximum rated voltage of 600V, and an IP69 degree of protection, ensuring durability and performance in demanding environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Angled 90º
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Blue
General Connection Type
Screw Connection
General Model
RST20I5 Male
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
