The Wieland RST20I5 Male Device Connector in Light Blue offers a secure screw connection in a straight angle plug design. With 5 poles and a thread size of M25, it supports a minimum rated voltage of 250 V up to 600 V to handle various applications. Meeting IP69 and Type 4X / 6P protection standards, it suits outdoor use and ensures reliable performance in demanding environments. Compliant with IEC and cULus wire size specifications, this connector is a robust solution for outdoor electrical connectivity.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Blue
General Connection Type
Screw Connection
General Model
RST20I5 Male
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M25
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
