Wieland RST20I5 Male Device Connector, Light Blue, 5 Poles, Straight Angle Plug
Wieland RST20I5 Male Device Connector, Light Blue, 5 Poles, Straight Angle Plug
SKU:CIR-f87e54
Wieland RST20I5 Male Device Connector, Outdoor-rated, 5 poles, Straight Angle, Light Blue
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I5 Male Device Connector, Light Blue, 5 Poles, Straight Angle Plug
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 Male Device Connector, Light Blue, 5 Poles, Straight Angle Plug
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Male Device Connector in Light Blue is a reliable solution for outdoor electrical connections. Featuring a screw connection and a straight angle plug, this connector is designed for durability and ease of use. With a thread size of M20 and IP69 protection rating, it ensures reliable performance in challenging environments. Rated for voltages up to 600V and currents of 20A, this connector meets international standards for wire sizes and offers secure connectivity for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Blue
General Connection Type
Screw Connection
General Model
RST20I5 Male
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
