Wieland RST20I5 Male Device Connector, Light Gray, 5 Poles, Outdoor Rated
Wieland RST20I5 Male Device Connector, Light Gray, 5 Poles, Outdoor Rated
SKU:CIR-29b0d2
Top-of-the-line Wieland RST20I5 Male Device Connector for outdoor electrical connections. Screw connection, IP69/Type 4X/6P protection, IEC/cULus compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I5 Male Device Connector, Light Gray, 5 Poles, Outdoor Rated
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 Male Device Connector, Light Gray, 5 Poles, Outdoor Rated
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Male Device Connector in Light Gray is a top-of-the-line solution for outdoor electrical connections. Featuring a secure screw connection and a straight angle plug, this connector ensures reliable performance in demanding environments. With a threaded size of M25 and a robust IP69/Type 4X/6P protection rating, it can handle voltages up to 600V and currents up to 20A. Compliant with IEC and cULus standards, this connector is suitable for a wide range of applications, including industrial and institutional settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Model
RST20I5 Male
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M25
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
