Wieland RST20I5 Male Device Connector, Straight Angle, Light Gray
Wieland RST20I5 Male Device Connector, Straight Angle, Light Gray
SKU:CIR-eb6647
High-performance outdoor-rated 5-pole male device connector by Wieland in Light Gray. IP69 and cULus Type 4X / 6P compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland RST20I5 Male Device Connector, Straight Angle, Light Gray
$24.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I5 Male Device Connector, Straight Angle, Light Gray
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I5 Male Device Connector in Light Gray features a screw connection and 5 poles, ideal for outdoor use. With a minimum rated voltage of 250 V and a maximum of 600 V, this connector offers a rated current of 20 A, suitable for a range of applications. Compliant with IP69 and cULus Type 4X / 6P standards, it ensures reliable performance in demanding environments.
Product Specifications
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Light Gray
General Connection Type
Screw Connection
General Model
RST20I5 Male
General Number Of Poles
5
Note Note
Technical details are subject to change
Specifications Type
Male
Technical Data Alternating Current Ac Voltage Disconnect Under L
350 V
Technical Data Current Disconnect Under Load Usa And Canada
20 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X / 6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Rated Current
20 A
Technical Data Thread Size
M20
Technical Data Wire Size According To Canadian Ul Listed United
18 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.75 to 4 mm²
