Wieland RST20I7S Circular Connector - 20A, Male, 7 Pole, IP68
Wieland RST20I7S Circular Connector - 20A, Male, 7 Pole, IP68
SKU:CIR-b3cc33
High-quality Wieland RST20I7S Circular Connector - 20A, Male, 7 Pole, IP68
Regular price
$32.99
Regular price
Sale price
$32.99
Unit price
per
Initiate Order
Wieland RST20I7S Circular Connector - 20A, Male, 7 Pole, IP68
$32.99
Quantity: 1
Claim Your Seller Account
Wieland RST20I7S Circular Connector - 20A, Male, 7 Pole, IP68
$32.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST20I7S S1 ZR2 SW Circular Connector is a high-quality pluggable electrical connector suitable for applications requiring 250/400V with PE. With a 20A rating, this connector accommodates cable diameters ranging from 10-14mm. Featuring a black housing color and strain relief for added durability, it meets IP66, IP68, and IP69 standards. The connector is designed with self-locking capability and is UL-certified for reliability. Its compliance with RoHS and REACH regulations ensures environmental sustainability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440605
Classification Etim 40 Classification
EC002560
Classification Etim 50 Classification
EC002560
Classification Etim 60 Classification
EC002560
Classification Etim 70 Classification
EC002560
Connection Data Maximum Cable Diameter
14 mm
Connection Data Maximum Fine Stranded Connection Cross Section
1.5 mm²
Connection Data Maximum Solid Connection Cross Section
1.5 mm²
Connection Data Maximum Stranded Connection Cross Section
14 AWG
Connection Data Minimum Cable Diameter
10 mm
Connection Data Minimum Fine Stranded Connection Cross Section
0.2 mm²
Connection Data Minimum Solid Connection Cross Section
0.2 mm²
Connection Data Minimum Stranded Connection Cross Section
20 AWG
Connection Data Sheath Strip Length
25 mm
Connection Data Terminations Per Pole
1
Connection Data Wire Strip Length
8 mm
Dimensions Height
34.6 mm
General Color Of Codingcontact Carrier
Black
General Color Of Housing Inclusive Strain Relief
Black
General Lockable
Self-Locking (Unlocking by Tool)
General Marking Of Poles
1 | 2 | 3 | 4 | 5 | 6 | N | PE
General Pollution Degree
3
General Rated Impulse Voltage
4 kV
General Strain Relief
Yes
Material Contact Material
Copper Zinc (CuZn)
Material Fire Load
0.317 kW·h
Material Halogen Free
Yes
Material Housing Material
Polyamide
Material Insulation Components Continuous Temperature
100 ºC
Material Surface Finish
Silver-Plated
Material Underwriters Laboratories Ul Certification
Underwriters Laboratories (UL)-V2
Material Underwriters Laboratories Ul Classification Strain Reli
Underwriters Laboratories (UL)-V2
Model Connection Type
Screw Connection
Model Degree Of Protection Ip
IP66 | IP68 (3m;2h) | IP69
Model Electrical Connector Type
Male
Note Note
3 poles max. 20A, 4 poles max. 5A
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Technical Data Maximum Rated Voltage
600 V
