Wieland RST25i3S Circular Electrical Connector 25A
Wieland RST25i3S Circular Electrical Connector 25A
SKU:CIR-ba0e27
High-quality 3-pole male circular connector for secure 25A connections in electrical applications. Durable, weather-resistant design with concrete gray coding and IP69 protection.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland RST25i3S Circular Electrical Connector 25A
$34.99
Quantity: 1
Claim Your Seller Account
Wieland RST25i3S Circular Electrical Connector 25A
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland RST25i3S S1 ZR2 V BG03 Circular Connector is a high-quality 3-pole male connector designed for electrical applications requiring a current rating of 25A and a voltage range of 250V to 600V. With a secure screw connection and self-locking mechanism, this connector ensures reliable and safe connections. Suitable for cable diameters between 10-14mm, it features a concrete gray coding for easy identification and a black housing with IP69 and Type 4X/6P protection ratings. Made of durable polyamide and copper zinc materials, it meets RoHS compliance standards and is halogen-free. Ideal for outdoor use, this connector offers exceptional performance and longevity.
Product Specifications
Classification Eclass 81 Classification
27440605
Classification Etim 40 Classification
EC002560
Classification Etim 50 Classification
EC002560
Classification Etim 60 Classification
EC002560
Classification Etim 70 Classification
EC002560
Connection Data Maximum Fine Stranded Connection Cross Section
6 mm²
Connection Data Maximum Solid Connection Cross Section
6 mm² | 10 AWG
Connection Data Maximum Stranded Connection Cross Section
10 AWG
Connection Data Minimum Fine Stranded Connection Cross Section
0.75 mm²
Connection Data Minimum Solid Connection Cross Section
0.75 mm² | 16 AWG
Connection Data Minimum Stranded Connection Cross Section
16 AWG
Connection Data Sheath Strip Length
26.5 mm
Connection Data Terminations Per Pole
1
Connection Data Wire Strip Length
8 mm
Dimensions Height
34.6 mm
General Angle Of Plug
Straight
General Brands
Wieland
General Color Of Codingcontact Carrier
Concrete Gray
General Color Of Housing Inclusive Strain Relief
Black
General Lockable
Self-Locking (Unlocking by Tool)
General Marking Of Poles
L | N | PE
General Model
RST25I3S S1 ZR2 V BG03
General Number Of Poles
3
General Pollution Degree
3
General Rated Impulse Voltage
4 kV
General Strain Relief
Yes
General Type
Male
Material Contact Material
Copper Zinc (CuZn)
Material Fire Load
0.268 kW·h
Material Halogen Free
Yes
Material Housing Material
Polyamide
Material Insulation Components Continuous Temperature
100 ºC
Material Surface Finish
Silver-Plated
Model Connection Type
Screw Connection
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Wire Size According To Canadian Ul Listed United
12 AWG Solid
Technical Data Wire Size According To International Electrotechn
0.75 to 6 mm²
