The Wieland RST50I5S B1 ZM02V SW Device Connector is a high-quality 5-pole female connector designed for outdoor use in application voltages of up to 400V and currents of 50A. It features a screw connection, position fixation, and black coding for easy identification. With a lockable design, this connector ensures secure connections in demanding environments. The connector is IP66, IP67, and IP69 rated, offering excellent protection against water and dust. Made of polyamide housing material with halogen-free and silver-plated components, it ensures durability and reliable performance. This connector meets RoHS conformity and REACH-SVHC requirements, making it an environmentally friendly and safe choice for your electrical connection needs.
Product Specifications
Classification Eclass 81 Classification
27440602
Classification Etim 40 Classification
EC002566
Classification Etim 50 Classification
EC002566
Classification Etim 60 Classification
EC002566
Classification Etim 70 Classification
EC002566
Connection Data Maximum Fine Stranded Connection Cross Section
16 mm²
Connection Data Maximum Solid Connection Cross Section
16 mm²
Connection Data Maximum Stranded Connection Cross Section
16 mm²
Connection Data Minimum Fine Stranded Connection Cross Section
4 mm²
Connection Data Minimum Solid Connection Cross Section
4 mm²
Connection Data Minimum Stranded Connection Cross Section
4 mm²
Connection Data Terminations Per Pole
1
Connection Data Wire Strip Length
10 mm
Dimensions Height
65 mm
Dimensions Length
65.7 mm
Dimensions Width
65 mm
General Brands
Wieland
General Color
Black
General Color Of Codingcontact Carrier
Black
General Lockable
Yes
General Marking Of Poles
1 | 2 | 3 | N | PE
General Maximum Rated Voltage
600 V
General Model
RST50I5S B1 ZM02V SW
General Number Of Poles
4
General Pollution Degree
3
General Rated Current
50 A
General Rated Impulse Voltage
4 kV
Material Contact Material
Copper Zinc (CuZn)
Material Fire Load
0.426 kW·h
Material Halogen Free
Yes
Material Housing Material
Polyamide
Material Insulation Components Continuous Temperature
80 ºC
Material Surface Finish
Silver-Plated
Model Angle Of Plug
Straight
Model Connecting Thread Metric
M32
Model Connection Type
Screw Connection
Model Connector Type
Female
Model Degree Of Protection
IP66 | IP67 | IP69
Model Thickness Of Housings Electrical Device
7 mm
Model Thickness Of Housings Electrical Device 2
2 mm
