Wieland SIN 9001 Actuating Switch
Wieland SIN 9001 Actuating Switch
SKU:SAF-05f581
Reliable Wieland SIN 9001 Actuating Switch for precise and durable performance. Compliant with RoHS and REACH-SVHC standards.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Wieland SIN 9001 Actuating Switch
$39.99
Quantity: 1
Claim Your Seller Account
Wieland SIN 9001 Actuating Switch
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland SIN 9001 Actuating Switch is a premium safety device designed with a Thermoplastic GV/ZN-GD actuating head material, ensuring reliable performance in a wide range of environments. With a separate actuator feature and an impressive mechanical life time of 10^7 switching cycles, this switch offers durability and precision. It operates smoothly between a minimum ambient temperature of -25°C and a maximum ambient temperature of 70°C. Compliant with RoHS and REACH-SVHC standards, this switch meets the highest quality and environmental regulations, making it an ideal choice for both consumer and institutional buyers.
Product Specifications
Classification Eclass 81 Classification
27270605
Classification Etim 50 Classification
EC001487
Classification Etim 60 Classification
EC001487
Classification Etim 70 Classification
EC001487
General Brands
Wieland
General Model
SIN 9001
Mechanical Data Actuating Head Material
Thermoplastic GV/ZN-GD
Mechanical Data Installation Position
Operator Definable
Mechanical Data Maximum Ambient Temperature
70 ºC
Mechanical Data Mechanical Life Time
107 Switching Cycles
Mechanical Data Minimum Ambient Temperature
-25 ºC
Mechanical Data Separate Actuator
Yes
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
