Wieland Turquoise Blue Female Splitter Connector 6mm Cable Diameter
Wieland Turquoise Blue Female Splitter Connector 6mm Cable Diameter
SKU:CIR-4b23f9
Wieland Turquoise Blue Female Splitter Connector with 6mm Cable Diameter for reliable outdoor electrical connections.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland Turquoise Blue Female Splitter Connector 6mm Cable Diameter
$29.99
Quantity: 1
Claim Your Seller Account
Wieland Turquoise Blue Female Splitter Connector 6mm Cable Diameter
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Turquoise Blue Female Splitter Connector with a minimum cable diameter of 6mm offers reliable screw connection technology suitable for outdoor use. This cULus and IEC compliant connector can handle up to 600V voltage and features a total of 6/7 poles for versatile electrical connectivity. With IP69 and Type 4X/6P protection ratings, this connector ensures durability in challenging environments, making it ideal for outdoor applications requiring secure and efficient electrical connections.
Product Specifications
Note Note
Technical details are subject to change
Specifications Color Of Codingcontact Carrier
Turquoise Blue
Specifications Connection Type
Screw Connection
Specifications Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) | 3 x 20 A + 4 x 5 A (USA)
Specifications Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Specifications Degree Of Protection According To Canadian Ul Rec
Type 4X/6P
Specifications Degree Of Protection According To International E
IP69
Specifications Maximum Cable Diameter
10 mm
Specifications Minimum Cable Diameter
6 mm
Specifications Model
Female
Specifications Number Of Poles
6
Specifications Standards
cULus-Listed | IEC
Specifications Voltage
250 V | 400 V | 600 V
Specifications Wire Size According To Canadian Ul Recognized Uni
20 to 14 AWG
Specifications Wire Size According To International Electrotechn
0.2 to 1.5 mm²
