Wieland Turquoise Blue Male Splitter Connector, 6mm Min Cable Diameter
Wieland Turquoise Blue Male Splitter Connector, 6mm Min Cable Diameter
SKU:CIR-14190a
Secure outdoor electrical connections with Wieland Turquoise Blue Male Splitter Connector. 7 poles, 6mm min cable diameter, cULus-Listed, IEC compliant.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland Turquoise Blue Male Splitter Connector, 6mm Min Cable Diameter
$34.99
Quantity: 1
Claim Your Seller Account
Wieland Turquoise Blue Male Splitter Connector, 6mm Min Cable Diameter
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Turquoise Blue Male Splitter Connector is a top-of-the-line solution designed for outdoor applications in need of reliable electrical connections. Featuring 7 poles, a screw connection type, and a robust construction, this connector ensures secure and efficient power distribution. With a minimum cable diameter of 6mm, it meets international standards such as cULus-Listed and IEC, offering a voltage range of 250V, 400V, and 600V. Additionally, its IP69 rated protection guarantees durability in harsh environments, making it ideal for institutional and government procurement needs.
Product Specifications
Note Note
Technical details are subject to change
Specifications Color Of Codingcontact Carrier
Turquoise Blue
Specifications Connection Type
Screw Connection
Specifications Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) | 3 x 20 A + 4 x 5 A (USA)
Specifications Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Specifications Degree Of Protection According To Canadian Ul Rec
Type 4X/6P
Specifications Degree Of Protection According To International E
IP69
Specifications Maximum Cable Diameter
10 mm
Specifications Minimum Cable Diameter
6 mm
Specifications Model
Male
Specifications Number Of Poles
7
Specifications Standards
cULus-Listed | IEC
Specifications Voltage
250 V | 400 V | 600 V
Specifications Wire Size According To Canadian Ul Recognized Uni
20 to 14 AWG
Specifications Wire Size According To International Electrotechn
0.2 to 1.5 mm²
