The Wieland Wienet UMS4-C-2SC-FM Switch is a high-performance networking solution suitable for both consumer and institutional buyers. With 4x RJ45 10/100 Mbps ports and 2 x SC (Multi Mode) FOC/SFP ports, this switch offers reliable connectivity. It features IEEE 802.3 standards, broadcast storm protection, and a transmission range of up to 20 km. Designed for durability with IP30 protection and metal housing, it operates in temperatures from -10°C to 60°C. With certifications like CE, cULus, FCC Part 15 Class A, and UL 60950-1, this switch ensures compliance and performance.
Product Specifications
Dimensions Approximate Weight
700 g
Dimensions Dimensions W X H X D
37 x 140 x 95 mm
General Brands
Wieland
General Diagnosis Display
Light Emitting Diode (LED)
General Model
Wienet UMS4-C-2SC-FM
General Rohs Certification
Yes
Specifications Note
Subject to technical modifications
Switch Properties Autonegotiation
Yes
Switch Properties Autopolarity
Yes
Switch Properties Autosensing
Yes
Switch Properties Broadcast Storm Protection
Yes
Switch Properties Communication
Full Duplex | Half Duplex
Switch Properties Ethernet Standards Institute Of Electrical And
802.3/802.3u/802.3x
Switch Properties Ethernet Transmission Length
100 mm
Switch Properties Optical Transmission Length
20 km
Switch Properties Topology
Line | Mesh | Star
Switch Properties Transmission Type
Store and Forward
Technical Data 10100 Mbps Ports
4x RJ45
Technical Data Focsfp Ports
2 x SC (Multi Mode)
Technical Features Housing Material
Metal
Technical Features Maximum Operating Direct Current Dc Voltage
48 V
Technical Features Maximum Operating Temperature
60 ºC
Technical Features Maximum Power Consumption
6.5 W
Technical Features Maximum Relative Humidity During Operation No
95 %
Technical Features Maximum Storage Temperature
85 ºC
Technical Features Minimum Operating Direct Current Dc Voltage
12 V
Technical Features Minimum Operating Temperature
-10 ºC
Technical Features Minimum Relative Humidity During Operation No
5 %
Technical Features Minimum Storage Temperature
-40 ºC
Technical Features Mounting Method
DIN Rail
Technical Features Norms And Approvals
CE | cULus | FCC Part 15 Class A | UL | UL 60950-1
Technical Features Protection Class
IP30
Technical Features Redundant Power Supply
2 Power Inputs
Technical Features Terminal Type
Pluggable Push-In Terminal
