Wieland Wienet IP Switch UMS8-W-M12
Wieland Wienet IP Switch UMS8-W-M12
SKU:IPS-293844
Wieland Wienet UMS8-W-M12 IP Switch - Reliable performance in harsh industrial environments. 8 M12 ports, IEEE 802.3 standards, IP67 protection, and multiple certifications.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
Wieland Wienet IP Switch UMS8-W-M12
$199.99
Quantity: 1
Claim Your Seller Account
Wieland Wienet IP Switch UMS8-W-M12
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Wienet UMS8-W-M12 Switch is a high-performance industrial-grade IP switch designed for reliable data transmission. With 8 M12 10/100 Mbps ports and IEEE 802.3 Ethernet standards, this switch ensures seamless communication in harsh environments. It features autonegotiation, autosensing, and broadcast storm protection for efficient network operation. With IP67 protection and CE, cULus, and FCC Part 15 Class A certifications, this switch meets rigorous industry standards for durability and safety.
Product Specifications
Dimensions Approximate Weight
700 g
Dimensions Dimensions W X H X D
62 x 194 x 25 mm
General Brands
Wieland
General Diagnosis Display
Light Emitting Diode (LED)
General Model
Wienet UMS8-W-M12
General Rohs Certification
Yes
Specifications Note
Subject to technical modifications
Switch Properties Autonegotiation
Yes
Switch Properties Autopolarity
Yes
Switch Properties Autosensing
Yes
Switch Properties Broadcast Storm Protection
Yes
Switch Properties Communication
Full Duplex | Half Duplex
Switch Properties Ethernet Standards Institute Of Electrical And
802.3/802.3u/802.3x
Switch Properties Topology
Line | Mesh | Star
Switch Properties Transmission Length
100 mm
Switch Properties Transmission Type
Store and Forward
Technical Data 10100 Mbps Ports
8x M12
Technical Features Housing Material
Metal
Technical Features Maximum Operating Direct Current Dc Voltage
48 V
Technical Features Maximum Operating Temperature
75 ºC
Technical Features Maximum Power Consumption
2.5 W
Technical Features Maximum Relative Humidity During Operation No
95 %
Technical Features Maximum Storage Temperature
85 ºC
Technical Features Minimum Operating Direct Current Dc Voltage
12 V
Technical Features Minimum Operating Temperature
-40 ºC
Technical Features Minimum Relative Humidity During Operation No
5 %
Technical Features Minimum Storage Temperature
-40 ºC
Technical Features Mounting Method
Wall
Technical Features Norms And Approvals
CE | cULus | EN50155 | FCC Part 15 Class A | IEC 61131-2 | UL
Technical Features Protection Class
IP67
Technical Features Redundant Power Supply
2 Power Inputs
Technical Features Terminal Type
M12 D-Coded
