Wieland Wienet UMS 16-2G Network Switch
Wieland Wienet UMS 16-2G Network Switch
SKU:IPS-58fe25
Enhance network connectivity with the Wieland Wienet UMS 16-2G Network Switch. 14x 10/100 Mbps RJ45 and 2x 10/100/1000 RJ45 ports, IEEE 802.3 compliance, and CE/FCC/UL certifications.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Wieland Wienet UMS 16-2G Network Switch
$249.99
Quantity: 1
Claim Your Seller Account
Wieland Wienet UMS 16-2G Network Switch
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Wienet UMS 16-2G Switch is a high-performance IP switch designed for reliable network connectivity. With 14x 10/100 Mbps RJ45 ports and 2x 10/100/1000 RJ45 ports, this switch offers versatile connection options. It boasts IEEE 802.3 standards compliance, a robust metal housing with IP30 protection, and a DIN Rail mounting method. Featuring autonegotiation, autosensing, and autopolarity, this switch ensures seamless data transmission. With certifications like CE, FCC, and UL, it meets stringent industry standards for quality and safety.
Product Specifications
Dimensions Approximate Weight
700 g
Dimensions Dimensions W X H X D
54 x 113 x 135 mm
General Brands
Wieland
General Diagnosis Display
Light Emitting Diode (LED)
General Model
Wienet UMS 16-2G
General Rohs Certification
Yes
Specifications Note
Subject to technical modifications
Switch Properties Autonegotiation
Yes
Switch Properties Autopolarity
Yes
Switch Properties Autosensing
Yes
Switch Properties Communication
Full Duplex | Half Duplex
Switch Properties Ethernet Standards Institute Of Electrical And
802.3/802.3u/x/ab 802.1 p
Switch Properties Flow Control
Back Pressure and Pause Frame-Based Flow Control Schemes
Switch Properties Media Access Control Mac Address Table
4 K
Switch Properties Packet Buffer Size
2.75 MB
Switch Properties Topology
Line | Mesh | Star
Switch Properties Transmission Length
100 mm
Switch Properties Transmission Type
Store and Forward
Technical Data 101001000 Rj45 Ports
2
Technical Data 10100 Mbps Ports
14x RJ45
Technical Features Housing Material
Metal
Technical Features Maximum Operating Direct Current Dc Voltage
48 V
Technical Features Maximum Operating Temperature
60 ºC
Technical Features Maximum Power Consumption
7.4 W
Technical Features Maximum Relative Humidity During Operation No
95 %
Technical Features Maximum Storage Temperature
70 ºC
Technical Features Minimum Operating Direct Current Dc Voltage
12 V
Technical Features Minimum Operating Temperature
-10 ºC
Technical Features Minimum Relative Humidity During Operation No
5 %
Technical Features Minimum Storage Temperature
-20 ºC
Technical Features Mounting Method
DIN Rail
Technical Features Norms And Approvals
CE | cULus | EN60950-1:2006 | FCC Part 15 Class A | UL | UL/ IEC(CB) 60950/62368
Technical Features Protection Class
IP30
Technical Features Redundant Power Supply
2 Power Inputs
Technical Features Terminal Type
Pluggable Push-In Terminal
