Wieland Wienet UMS 20-16G-4SFP-W Managed Switch
Wieland Wienet UMS 20-16G-4SFP-W Managed Switch
SKU:IPS-5138e1
Enhance network performance with the Wieland Wienet UMS 20-16G-4SFP-W Managed Switch. Reliable, efficient, and compliant with industry standards.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Wieland Wienet UMS 20-16G-4SFP-W Managed Switch
$349.99
Quantity: 1
Claim Your Seller Account
Wieland Wienet UMS 20-16G-4SFP-W Managed Switch
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Wienet UMS 20-16G-4SFP-W is a high-performance managed switch designed for reliable network connectivity. With 16 Gigabit RJ45 ports and 4 SFP ports, this switch offers versatile configuration options. It features store-and-forward transmission, IEEE 802.3 standards compliance, and a robust metal housing for durability. From autonegotiation to full duplex support, this switch ensures seamless communication. With certifications such as CE and UL61010-2-2, it meets stringent industry standards.
Product Specifications
Dimensions Approximate Weight
700 g
Dimensions Dimensions W X H X D
74 x 152 x 105 mm
General Brands
Wieland
General Diagnosis Display
Light Emitting Diode (LED)
General Model
Wienet UMS 20-16G-4SFP-W
General Rohs Certification
Yes
Specifications Note
Subject to technical modifications
Switch Properties Autonegotiation
Yes
Switch Properties Autopolarity
Yes
Switch Properties Autosensing
Yes
Switch Properties Communication
Full Duplex | Half Duplex
Switch Properties Ethernet Standards Institute Of Electrical And
802.3/802.3u/x
Switch Properties Jumbo Frame
10 kB
Switch Properties Media Access Control Mac Address Table
8 K
Switch Properties Packet Buffer Size
4.1 MB
Switch Properties Topology
Line | Mesh | Star
Switch Properties Transmission Length
100 mm
Switch Properties Transmission Type
Store and Forward
Technical Data 101001000 Rj45 Ports
16
Technical Data Focsfp Ports
4
Technical Features Housing Material
Metal
Technical Features Maximum Operating Direct Current Dc Voltage
48 V
Technical Features Maximum Operating Temperature
75 ºC
Technical Features Maximum Power Consumption
15 W
Technical Features Maximum Relative Humidity During Operation No
95 %
Technical Features Maximum Relay Output Direct Current Dc Voltag
24 V
Technical Features Maximum Storage Temperature
85 ºC
Technical Features Minimum Operating Direct Current Dc Voltage
12 V
Technical Features Minimum Operating Temperature
-40 ºC
Technical Features Minimum Relative Humidity During Operation No
10 %
Technical Features Minimum Storage Temperature
-40 ºC
Technical Features Mounting Method
DIN Rail
Technical Features Norms And Approvals
CE | cULus | FCC Part 15 Class A | IEC60950 | NEMA TS2 | UL | UL61010-2-201
Technical Features Protection Class
IP30
Technical Features Redundant Power Supply
2 Power Inputs
Technical Features Relay Output Current
1 A
Technical Features Terminal Type
Pluggable Push-In Terminal
