Wieland Wienet UMS8-C IP Switch
Wieland Wienet UMS8-C IP Switch
SKU:IPS-1fa695
High-performance Wieland Wienet UMS8-C IP Switch for reliable networking. 8x RJ45 10/100 Mbps ports, IEEE 802.3 compliant. Robust metal housing, IP30 protection.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Wieland Wienet UMS8-C IP Switch
$249.99
Quantity: 1
Claim Your Seller Account
Wieland Wienet UMS8-C IP Switch
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Wienet UMS8-C Switch is a top-tier IP switch designed for seamless network connectivity. Featuring 8x RJ45 10/100 Mbps ports, this switch ensures reliable data transmission with autonegotiation and autosensing capabilities. With IEEE 802.3 standards compliance, full/half duplex communication, and store-and-forward transmission, it offers versatility for various networking needs. Moreover, this switch boasts a robust metal housing, DIN rail mounting, and IP30 protection class for durable and secure installations. Meet your networking demands with this CE, cULus, FCC Part 15 Class A, UL, and UL 62368 certified switch.
Product Specifications
Dimensions Approximate Weight
460 g
Dimensions Dimensions W X H X D
30 x 140 x 95 mm
General Brands
Wieland
General Diagnosis Display
Light Emitting Diode (LED)
General Model
Wienet UMS8-C
General Rohs Certification
Yes
Specifications Note
Subject to technical modifications
Switch Properties Autonegotiation
Yes
Switch Properties Autopolarity
Yes
Switch Properties Autosensing
Yes
Switch Properties Communication
Full Duplex | Half Duplex
Switch Properties Ethernet Standards Institute Of Electrical And
802.3/802.3u/802.3x
Switch Properties Topology
Line | Mesh | Star
Switch Properties Transmission Length
100 mm
Switch Properties Transmission Type
Store and Forward
Technical Data 10100 Mbps Ports
8x RJ45
Technical Features Housing Material
Metal
Technical Features Maximum Operating Direct Current Dc Voltage
48 V
Technical Features Maximum Operating Temperature
60 ºC
Technical Features Maximum Power Consumption
5 W
Technical Features Maximum Relative Humidity During Operation No
95 %
Technical Features Maximum Storage Temperature
85 ºC
Technical Features Minimum Operating Direct Current Dc Voltage
12 V
Technical Features Minimum Operating Temperature
-10 ºC
Technical Features Minimum Relative Humidity During Operation No
5 %
Technical Features Minimum Storage Temperature
-40 ºC
Technical Features Mounting Method
DIN Rail
Technical Features Norms And Approvals
CE | cULus | FCC Part 15 Class A | UL | UL 62368
Technical Features Protection Class
IP30
Technical Features Redundant Power Supply
2 Power Inputs
Technical Features Terminal Type
Pluggable Push-In Terminal
