Enhance your power system with the Wieland Wipos P3 24-5 Basic Line Power Supply. This robust switched-mode power supply delivers a reliable 24V DC / 5A output with a wide input voltage range suitable for industrial applications. It features sustained short-circuit protection, compact dimensions, and a durable metal housing. With compliance to various international standards, including UL and EN, this power supply ensures safety and efficiency in demanding environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27049002
Classification Etim 50 Classification
EC002540
Classification Etim 60 Classification
EC002540
Classification Etim 70 Classification
EC002540
Dimensions Depth
119 mm
Dimensions Height
124 mm
Dimensions Horizontal Mounting Distance
25 mm
Dimensions Vertical Mounting Distance
25 mm
Dimensions Weight
800 g
Dimensions Width
74.3 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Continuous Current
5 A
General Degree Of Protection Ip
IP20
General Direct Current Dc Output Voltage
24 V
General Housing Material
Metal
General Maximum Operating Temperature
71 ºC
General Maximum Relative Humidity Rh
95 %
General Maximum Transport Storage Temperature
-40 ºC
General Minimum Operating Temperature
-40 ºC
General Minimum Relative Humidity Rh
20 %
General Minimum Transport Storage Temperature
85 ºC
General Model
Wipos P3 24-5
General Modular Version
No
General Nominal Alternating Current Ac Input Voltage
340 to 575 V
General Nominal Direct Current Dc Input Voltage
480 to 820 V
General Number Of Phases
3 Phase Power Supply
General Power
120 W
Input Maximum Alternating Current Ac Input Voltage
575 V
Input Maximum Direct Current Dc Input Voltage
820 V
Input Minimum Alternating Current Ac Input Voltage
340 V
Input Minimum Direct Current Dc Input Voltage
480 V
Input Power Consumption
< 266 V·A
Output Maximum Output Voltage
28.5 V
Output Minimum Output Voltage
22.5 V
Output Output Voltage
24 V
Output Output Voltage Stabilized
Yes
Output Power Output
120 W
Output Type Of Output Voltage
Direct Current (DC)
Technical Data Direct Current Dc Output Isolating Voltage
4242 V
