The Wieland WK 4 SI-D/U 5 X20/V0 Feed-Through Terminal Block is a high-quality DIN rail terminal block designed for secure electrical connections. With a nominal cross-section of 4 mm² and a maximum rated voltage of 800 V, this terminal block ensures reliable performance. Its screw connection design allows easy mounting on TS 35 and TS 32 rails. The terminal block's V0 inflammability class and compliance with RoHS and REACH-SVHC standards make it a safe and environmentally friendly choice for both consumer and institutional applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27141116
Classification Etim 30 Classification
EC000899
Classification Etim 40 Classification
EC000899
Classification Etim 50 Classification
EC000899
Classification Etim 60 Classification
EC000899
Classification Etim 70 Classification
EC000899
Connection Data Connection Type 1
Screw Connection
Connection Data Connection Type 2
Screw Connection
Connection Data Maximum Fine Stranded Cross Section
4 mm²
Connection Data Maximum Solid Cross Section
6 mm²
Connection Data Minimum Fine Stranded Cross Section
0.5 mm²
Connection Data Minimum Solid Cross Section
0.5 mm²
Connection Data Wire Strip Length
9 mm
General Brands
Wieland
General Color
Gray
General Fuse Insert
G-Fuse 5x20 mm
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WK 4 SI-D/U 5 X20/V0
General Mounting Method
DIN Rail (Top Hat Rail) | G-Rail
General Nominal Cross Section
4 mm²
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
No
General Width Grid Dimension
12 mm
Note Note
Remark to rated voltage - Note fuse insertRemark to rated current - Note fuse insert
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
Yes
Technical Data Length
48 mm
Technical Data Maximum Rated Voltage
800 V
Technical Data Pollution Degree
3
Technical Data Rated Current
6.3 A
Technical Data Rated Impulse Voltage
8 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
20-10 AWG
Technical Data Ulcsa Factory Wiring Current
10 A
Technical Data Ulcsa Torque Conductor Mounting
0.5 N·m
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
250 V
