Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block
Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block
SKU:DIN-f17994
Reliable Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block for secure electrical installations.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block
$29.99
Quantity: 1
Claim Your Seller Account
Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland WK 4/THSI5 LED 24U/V0 Fuse Terminal Block is a reliable solution for electrical installations, featuring a G-Fuse insert, 6.3 A rated current, and a maximum rated voltage of 24 V. With dual screw connections for secure wiring, this gray terminal block meets industry standards for insulation material inflammability (V0), torque conductor mounting, and RoHS compliance. Suitable for DIN rail mounting, it offers ease of installation and maintenance, making it ideal for both consumer and institutional buyers seeking durability and safety.
Product Specifications
Classification Eclass 81 Classification
27141116
Classification Etim 30 Classification
EC000899
Classification Etim 40 Classification
EC000899
Classification Etim 50 Classification
EC000899
Classification Etim 60 Classification
EC000899
Classification Etim 70 Classification
EC000899
Connection Data Connection Type 1
Screw Connection
Connection Data Connection Type 2
Screw Connection
Connection Data Maximum Fine Stranded Cross Section
4 mm²
Connection Data Maximum Solid Cross Section
6 mm²
Connection Data Minimum Fine Stranded Cross Section
0.5 mm²
Connection Data Minimum Solid Cross Section
0.5 mm²
Connection Data Wire Strip Length
8 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WK 4/THSI 5 LED 24U /V0
General Mounting Method
DIN Rail (Top Hat Rail) | G-Rail
General Nominal Cross Section
4 mm²
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
No
General Width Grid Dimension
8 mm
Note Defect Indicator
LED
Note Maximum Operating Voltage Of Defective Display
24 V
Note Minimum Operating Voltage Of Defective Display
12 V
Note Remark To Maximum Rated Voltage
Note max power loss
Note Remark To Rated Current
Note max power loss
Note Voltage Type For Defect Indication
Alternating Current (AC)/Direct Current (DC)
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Closing Plate Required
No
Technical Data Fuse Insert Size
5 x 20 mm
Technical Data Maximum Rated Voltage
24 V
Technical Data Rated Impulse Voltage
8 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Voltage Canadian Standards Association Csa
24 V
