Wieland WKF 16/35 Feed-Through Terminal Block
Wieland WKF 16/35 Feed-Through Terminal Block
SKU:DIN-c871ca
Reliable Wieland WKF 16/35 Feed-Through Terminal Block with 16 mm² cross-section, 76 A current, and V0 inflammability for secure electrical connections.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland WKF 16/35 Feed-Through Terminal Block
$34.99
Quantity: 1
Claim Your Seller Account
Wieland WKF 16/35 Feed-Through Terminal Block
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland WKF 16/35 Feed-Through Terminal Block is a high-quality solution for electrical installations, featuring tension spring connections and a mounting compatible with TS35 DIN rails. With a nominal cross-section of 16 mm², this gray terminal block provides a reliable connection with a rated current of 76 A and a maximum rated voltage of 800 V. Its robust construction, flame-retardant insulating housing (PA666), and compliance with RoHS and REACH-SVHC standards make it a top choice for both consumer and institutional buyers looking for safety and reliability in their electrical setups.
Product Specifications
Classification Eclass 81 Classification
27141120
Classification Etim 30 Classification
EC000897
Classification Etim 40 Classification
EC000897
Classification Etim 50 Classification
EC000897
Classification Etim 60 Classification
EC000897
Classification Etim 70 Classification
EC000897
Connection Data Connection Type 1
Spring Clamp Connection
Connection Data Connection Type 2
Spring Clamp Connection
Connection Data Maximum Fine Stranded Cross Section
16 mm²
Connection Data Maximum Solid Cross Section
10 mm²
Connection Data Maximum Stranded Cross Section
16 mm²
Connection Data Minimum Fine Stranded Cross Section
4 mm²
Connection Data Minimum Solid Cross Section
4 mm²
Connection Data Minimum Stranded Cross Section
16 mm²
Connection Data Wire Strip Length
15 mm
General Brands
Wieland
General Color
Gray
General Explosion Tested Version Ex E
Yes
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WKF 16/35
General Mounting Method
DIN Rail (Top Hat Rail)
General Nominal Cross Section
16 mm²
General Number Of Clamp Positions Per Level
2
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
Yes
General Width Grid Dimension
12 mm
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
No
Technical Data Length
82 mm
Technical Data Maximum Rated Voltage
800 V
Technical Data Pollution Degree
3
Technical Data Rated Current
76 A
Technical Data Rated Impulse Voltage
8 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Canadian Standards Associatio
12-4 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
24-4 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
600 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
600 V
